  1. Its for the front camera which has a split lens that shows a view left & right at junctions, it can be switched on/off via the switch on the right hand side of the steering wheel
  2. It is only the facelift 3.0Litre from 2005 on wards that had a 5 speed, 4-speed automatic: U140E (pre-facelift 3.0) U140F (2.4 AWD/pre-facelift 3.0 AWD) U241E (2.4 FWD) P210 e-CVT (hybrid) 5-speed automatic (facelift 3.0): U151E (FWD) U151F (AWD)
  3. Well done, not something I would fancy doing in this weather
  4. If it looks the same then it more than likely is as the shell/chassis is the same it was just the style that changed depending on model, e.g. AS, MS, you can check in the link for part numbers amayama.com
  5. You need a scanner with the JOBD protocol to read the fault codes, once you have a code you can google it, you will then have a very good idea on which part to replace, with out the code you will just be throwing money at it, a good scanner is the Ancel JP700
  6. Tensioner should not need doing unless a very high mileage, if your rad has the plastic side panels they can crack due to age and heat but you can get radiators with metal sides on ebay, new hoses is agood idea, also towards the back there are 2 T joints that take the coolant into the heater matrix, they are made of plastic and can get brittle due to the heat/age some people, my self included, fit brass T pieces, 19mm, again on ebay, the link will be helpful for any part numbers you might need for other bits, once you have a part number you can use it as a cross reference or ask a toyota dealer to get it or even get it through the link amayama.com
  7. As it is an inline 4 it is possible to do it in-situ, however it is advisable to have the head skimmed to ensure it has not warped so search for a place local to you that can do that
  8. Yes, as long as you have a sensor pre & post the manifold cat
  9. Get an Ancel JP700 scanner or any other make that has the JOBD protocol, a lot of people fit universal 02 sensors where they have to wire the pins to suit the vehicle, that could be why your wiring is a mess, look for a Denso or Blueprint or FebiBilstein sensor
  10. the 2nd cat was fitted on the 2.4L to comply with the cold start emissions test which is not part of the uk mot
  11. It is a personal choice as some people go for an Android head unit others go for a more conventional unit such as a Pioneer or a Kenwood, you need to make a list of what features you would like, e.g. Satnav, Bluetooth, Phone mirroring, Dab radio, CD player, Reversing camera, what ever you choose you will need an adapter loom for the steering wheel controls, also a 12v rear camera & front if 1 is fitted as the oem are poor quality & 6v, I chose an ex-display Pioneer AVIC-Z620BT
  12. Possible causes; ball joints, worn bush(s) in lower arms, steering rack bushes, noise from the centre area could be engine mount
  13. Sounds like the drive cable, (bowden type) has jammed the pulleys inside the door, it is a known fault. The cable has a plastic outer which gets brittle and breaks up, the bits foul the pulleys/motor, as the cable is under tension you have to release the tension to allow the door to move freely, cut the cable close to the entry point on the door and remove it from the channel under th rear quarter window this will allow you to open/close the door manually, switch off the "power door" on the dash. Replacements are available off ebay and youtube has videos on how to fit the mechanism, https://www.ebay.co.uk/itm/354878093116
  14. Check out PCT Towbars they are ISO No.55 approved, they come complete with nuts/bolts etc, if you contact them they will have a list of approved fitters, https://www.pctautomotive.com/towbars
  15. As I recall the loom comes with instructions for a variety of different manufacturers and is just plug & play as the plugs & sockets are standard, the only awkward wire is the 1 that goes to the reversing camera which if it is the original factory fit could be 6volt, adapters are on ebay or just fit a 12v camera which will be of better quality, I actually fitted a wifi 1, the link is the adapter I used for my 2003 with a Pioneer unit https://www.ebay.co.uk/itm/373176086232
×
×
