it can be changed to a single bleep on open and on close, rather than the beep beep beep beep sound.

I don't think you need to remove the entire console to get to the bulbs, just the plastic lens. It should prise out using a guitar pick or plastic tool or similar.

the parking sensors utilise the blue square gvif connector to the headunit via the IPA ECU to provide visual feedback. The IPA ECU also sends an o/p to the amplifier and uses the drivers side speaker or centre speaker where available to provide the beeps and the japanese voice that yells at you. When I was experimenting, by disconnecting the GVIF connector, the headunit reverted to a different display for the sensors, and the sound persisted, so there may be some data sent via the canbus.

Yep, unfortunately in Japanese, I found those last year, before tracking down the english owners manual. Thanks for the reminder of that link though

I have ordered from amayama, was painless, and for the parts I needed (part of dashboard trim, and new light stalk) it was cheaper than other sites.

how many 'clicks' did you press it down?, mine holds fine.

shows all plugs and wiring. following shows just the main plug with reverse, parking brake and speed sense

front cam actually goes to a separate intelligent parking assistant computer, from there it uses the blue digital connection. you need a separate unit that converts this to a standard phono connector

I posted wiring on a thread a couple of days ago

let's be thankful is a Toyota, my friends Merc c class is always throwing fits and error messages, latest thing is the reverse cam has stopped functioning, and it has a motorized cover on it so will be probably the cost of a set of tyres to replace

no, gen 1 is a single panel, and because it's held by two screws on lower rim is not possible to remove without damage, whilst door closed. 20 series has 4 removable panels to access the bulbs and lock

on the rear panel, there is a panel that is removed to access the manual override with a screwdriver

I suppose you cannot access the lock panel cover, if bed in way?

Checked on amayama.com, part numbers, searched for them with uk stock, or you could go with importing via amayama: https://www.buycarparts.co.uk/oen/4243158020 https://www.buycarparts.co.uk/oen/4351228190 (amayama search here: https://www.amayama.com/en/genuine-catalogs/epc/toyota-japan/alphard/GGH25W/63675/chassis) Thats the front/rear discs, the pads are common across many toyota, but use amayama to get the part numbers.

so you have a GGH25?

I PMed you a link to my google share, with the wiring diagram and manuals

Steering control is socket D pins 23,24,25)

I don't want to get struck with a copyrght complaint, so have complied with sharing less than 20% - this shows the socket letters and pin numbers. Interestingly, should be able to use the inbuilt microphone, with some careful testing (socket D pins 4,5,6,7,20)

it should do, the cameras will be on the blue connector in car, the box converts the video to regular phono lead, so it should show what you would ordinarily see - Not sure if it is interactive though, as I dont see how it will communicate back the other way. the steering control is 3 wires on the main power plug, so this should be fine too

the brown socket on that head unit is used by the rear screen for the digitally superimposed info, such as volumn, icons, etc. The blue is for the intelligent parking assist ecu connection (It feeds in the front and side cameras) the 1st 2 connectors are both for the TV antennas, one at front of car and one at back (in spoiler) the 3rd connector on the 2nd row is telematics (GBOOK, toyota connect, emergency services - it actually has a usb protocol, so would be interesting if we can reuse this for some other purpose) the 4th socket is the aux video/audio input. the large socket on the bottom right is actually 2 sockets in one, the 8 pins on the left are the Amplifier connection.

Yes, that convertor would work (MOST is the communications protocol for the amplifier etc, there is a fair amount of crossover between 2004>2012 between LIN, MOST and the video protocol using GVIF and LVDS)
